Móðurborð 1151 Asus TUF Z390M Pro Gaming mATX

Asus

Glænýtt móðurborð frá Asus með nýja Intel Z390 kubbasettinu sem styður alla Intel Coffee Lake örgjörva beint úr kassanum, þ.m.t. áttundu og nýjundu kynslóð Intel Core.

  • Upplý...

Glænýtt móðurborð frá Asus með nýja Intel Z390 kubbasettinu sem styður alla Intel Coffee Lake örgjörva beint úr kassanum, þ.m.t. áttundu og nýjundu kynslóð Intel Core.

  • Upplýsingar
ASUS TUF Z390M-Pro Gaming LGA1151 (Intel 8th and 9th Gen) Micro ATX DDR4 HDMI M.2 USB 3.1 Gen2 Gigabit LAN (mATX) Motherboard, Black

Description
  • TUF Protection: SafeSlot, ESD guards, DDR4 overvoltage protection, Digi+ VRM and stainless-steel back I/O for long-term reliability
  • Military-grade TUF Components: TUF LANGuard, TUF chokes, TUF capacitors and TUF MOSFETs for maximum durability
  • OptiMem II: Careful routing of traces and vias, plus ground layer optimizations to preserve signal integrity for improved memory overclocking
  • MemOK II: Automatically fixes boot failures that arise due to memory overclocking and instability
  • Realtek S1200A Codec: Features an unprecedented 108dB signal-to-noise ratio for the stereo line-out and a 103dB SNR for the line-in, providing pristine audio quality
  • GPU Temperature Sensing and Fan Xpert 4: Ensures every fan achieves the best balance of cooling performance and acoustics
  • Aura Sync RGB: Synchronize LED lighting with a vast portfolio of compatible PC gear
    Product Description: ASUS TUF Z390M-PRO GAMING - motherboard - micro ATX - LGA1151 Socket - Z390
    Product Type: Motherboard - micro ATX
    Chipset Type: Intel Z390
    Processor Socket: 1 x LGA1151 Socket
    Compatible Processors: Celeron, Core i5, Core i3, Core i7, Core i9, Pentium Gold (supports 9th and 8th Generation Intel Core / Pentium Gold / Celeron)
    Max. RAM Size: 64 GB
    RAM Supported: 4 DIMM slots - DDR4, non-ECC, unbuffered
    Storage Ports: 6 x SATA-600 (RAID), 2 x M.2
    USB / FireWire Ports: USB 3.1 Gen 1, USB 3.1 Gen 2, USB-C Gen1 1 x USB-C Gen 1 + 1 x USB 3.1 Gen 2 + 4 x USB 3.1 Gen 1 + (1 x USB 3.1 Gen 2 + 2 x USB 3.1 Gen 1 + 4 x USB 2.0 via headers)
    Audio: HD Audio (8-channel)
    LAN: Gigabit Ethernet

    Technical description
    General

    Product Type: Motherboard - micro ATX
    Chipset Type: Intel Z390
    Processor Socket: LGA1151 Socket
    Max. Processors Qty: 1
    Compatible Processors: Celeron, Core i5, Core i3, Core i7, Core i9, Pentium Gold (supports 9th and 8th Generation Intel Core / Pentium Gold / Celeron)
    Supported RAM
    Max. Size: 64 GB
    Technology: DDR4
    Bus Clock: 2400 MHz, 2133 MHz, 2666 MHz, 2800 MHz (O.C.), 3000 MHz (O.C.), 3200 MHz (O.C.), 3300 MHz (O.C.), 3400 MHz (O.C.), 3333 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4266 MHz (O.C.)
    Supported RAM Integrity Check: Non-ECC
    Registered or Buffered: Unbuffered
    Features: Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
    Audio
    Type: HD Audio (8-channel)
    Audio Codec: Realtek ALCS1200A
    Compliant Standards: High Definition Audio, DTS Custom
    LAN
    Network Controller: Intel I219V
    Network Interfaces: Gigabit Ethernet
    Expansion / Connectivity
    Expansion Slots: 1 x CPU, 4 x DIMM 288-pin, 2 x PCIe 3.0 x16 (x16, x8/x8, x8/x4+x4, x8+x4+x4/x0 modes), 1 x PCIe 3.0 x1
    Storage Interfaces: SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5, SATA-600 / PCIe 3.0 -connectors: 1 x M.2, PCIe 3.0 -connectors: 1 x M.2
    RAID Features: Intel Rapid Storage Technology
    Interfaces: 1 x HDMI, 1 x LAN (Gigabit Ethernet), 1 x USB 3.1 Gen 2, 1 x PS/2 mouse, 1 x PS/2 keyboard, 1 x DisplayPort, 1 x USB-C Gen1, 1 x audio line-out - mini-jack, 1 x microphone - mini-jack, 1 x audio line-in - mini-jack, 4 x USB 3.1 Gen 1
    Internal Interfaces: 4 x USB 2.0 - header, 2 x USB 3.1 Gen 1 - header, 1 x serial - header, 1 x USB 3.1 Gen 2 - header, 1 x SPDIF out - header, 1 x audio - header
    Power Connectors: 24-pin main power connector, 8-pin ATX12V connector
    Features
    BIOS Type: AMI
    BIOS Features: Multilingual BIOS, ASUS Quiet Thermal Solution, UEFI BIOS, ASUS EZ Flash 3, ACPI 6.1 support, SMBIOS 3.1 support
    Sleep / Wake Up: Wake on LAN (WOL), wake on PME
    Hardware Features: C.P.R. (CPU Parameter Recall), jack retasking, NVIDIA SLI Technology Support, ASUS Q-Design, Q-DIMM, ASUS EZ DIY, Q-Slot, CrashFree BIOS 3, ASUS Q-Connector, audio jack detect technology, ASUS EPU (Energy Processing Unit), Intel Clear Video HD Technology, AMD CrossFireX technology support, Intel InTru 3D Technology, Intel Insider, Intel Quick Sync Video, Preboot eXecution Environment (PXE), ASUS Stainless Steel Back I/O, ASUS O.C. Tuner, Turbo LAN, TUF ESD Guards, TUF LANGuard, ASUS Overvoltage Protection, TUF Components, AURA RGB Lighting Control, ASUS Fan Xpert 4, ASUS SafeSlot, Intel Turbo Boost Technology 3.0, Intel Optane Memory Ready, ASUS TUF Protection, ASUS Aura Sync, TUF Gaming Armor, ASUS OptiMem II, MemOK! II, TUF Gaming Audio Cover
    Miscellaneous
    Included Accessories: I/O back plate, 1 x M.2 screw, TUF stickers
    Cables Included: 2 x Serial ATA cable, 1 x SLI bridge
    Software Included: Drivers & Utilities, ASUS AI Charger, ASUS AI Suite III, ASUS EZ Update, Antivirus (OEM version), PC Cleaner
    Compliant Standards: Plug and Play
    Dimensions:
    Width 24.4 cm, Depth 24.4 cm
