Switch PoE TP-Link GE TL-SG1008P 8port með 4xPoE

TP-Link

8 porta Gigabit switch og þar af styðja 4 port PoE

Þessi fjögur PoE port gera kleift að senda rafmagnið í sama kapli og þarf því eingöngu einn netkapal á milli búnaða...

8 porta Gigabit switch og þar af styðja 4 port PoE

Þessi fjögur PoE port gera kleift að senda rafmagnið í sama kapli og þarf því eingöngu einn netkapal á milli búnaðar og PoE switch. Þannig má stækka netkerfið þó svo að ekkert rafmagn sé nálægt tækjum eins og aðgangspunktum, IP myndavélum, IP símum o.s.frv.

  • Hraði: 1 Gbps
  • 8 port með Gigabit nethraða. Sjálfvirk skynjun
  • Þar af styðja 4 port Power over Ethernet (PoE)
  • Einföld tenging, plug & play
  • Uppfyllir EEE (Energy Efficient Ethernet) 802.3 staðalinn
  • Upplýsingar
TP-Link TL-SG1008P 8-Port Gigabit Desktop Switch w/ 4-Port PoE

Specifications

  • Mfr. Part Number: TL-SG1008P
  • Features:
    • Supports PoE power up to 15.4W for each PoE port
    • Supports PoE power up to 53W for all PoE ports
    • Supports PoE IEEE 802.3af compliant PDs
    • Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
    • 8K entry MAC address table of the TL-SG1008P with auto-learning and auto-aging
    • LED indicators for monitoring power, link, activity and speed
    • External power adapter supply
  • Hardware Features:
    • Interfaces: 8x 10/100/1000Mbps RJ45 Ports (AUTO Negotiation/ AUTO MDI/ MDIX)
    • Network Media:
      • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m)
      • 100BASE-TX: UTP category 5, 5e cable (maximum 100m, EIA/TIA-568 100Ω STP (maximum 100m)
      • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m)
    • PoE Ports (RJ45):
      • Standard: 802.3 af compliant
      • PoE Ports: Port1- Port4
      • Power Supply: 53W
    • Backbound Bandwidth: 16Gbps
    • Mac Address Table: 8K
    • External Power Supply: External Power Adapter (Output - 48VDC / 1.25A)
    • Fan Quantity: Fanless
    • Dimensions (WxDxH): 171.0 x 98.0 x 27.0 mm
  • Software Features:
    • Transmission Method: Store-and-Forward
    • Advanced Functions:
      • Compatible With IEEE 802.3af Compliant PDs
      • Priority Function
      • Mac Address Auto-Learning And Auto-Aging
      • IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode
  • Others:
    • Certification: FCC, CE, RoHS
    • Package Contents: TL-SG1008P, Power Adapter, User Guide
    • Consumption: 5.8W (max no PD connected), 58.8W (max with 53w PD connected)
    • Environment:
      • Operating Temperature: 0°C~40°C (32°F~104°F)
      • Storage Temperature: -40°C~70°C (-40°F~158°F)
      • Operating Humidity: 10%~90% non-condensing
      • Storage Humidity: 5%~90% non-condensing
