(*1) Not compatible with Nissin Battery Magazine BM-01
(*2) Not correspond to the wireless optical TTL master. Can be set as A/B/C group (*3) SD: Pre-flash, SF:Flash
S...
(*1) Not compatible with Nissin Battery Magazine BM-01
(*2) Not correspond to the wireless optical TTL master. Can be set as A/B/C group (*3) SD: Pre-flash, SF:Flash
Signal by Air 1
Air 1 Specifications
Guide no. (at ISO 100 in m) | GN54 (at 200mm zoom head position)GN48 (at 105mm zoom head position)GN28 (at 35mm zoom head position) |
Focal length coverage | 24 - 200mm (16mm when using build-in wide panel) |
Power Source | Four size-AA batteries |
Battery loading system | Quick loading – Battery Magazine (BM-02) (*1) |
Recycling Time | 0.1 - 4 sec |
Number of flashes (Approx.) | 200 - 1500 flashes |
Flash duration | 1/800 - 1/30,000 Sec |
Color Temperature | 5,600K |
Exposure control | E-TTL II / E-TTL (Canon), i-TTL (Nikon) and ADI/P-TTL (Sony) |
Wireless Mode | 2.4GHz Wireless TTL Slave: radio transmission (NAS specifications). Optical Wireless TTL Slave (only correspond to the same brand of camera systems) (*2) Optical slave mode (*3) (SD / SF mode) |
EV compensation on flash | -2 to +2 EV in increments of 1/2 EV |
Bounce position | Up: 90°, Down: 7°, Left: 180°, Right 180° (with flash head tilting / rotating lock release button) |
Flash exposure control | 1st- Curtain synchronization, 2nd- Curtain synchronization, High- speed synchronization, Red-eye reduction, Slow synchronization (only available on Nikon Model), FE / FV Lock (set on camera) |
AF-assist beam effective range | 0.7 – 6m/ 2.3 – 19.7 feet |
Operation panel | LED Color panel, select dial |
External service ports | External power source socket, standard and 3.5mm PC sync terminal |
Radio specifications | 2.4GHz ISM band (Obtaining technical standards conformity certification) |
Accessories | Soft case, flash stand (with screw) |
Channel | 8 channels (Channel setting in Air 1) |
Dimensions | 140(H) x 75(W) x 115(D) mm/ 5.5 (H) x 3(W) x 4.5(D) inches |
Weight | 380g/ 13.4oz (without batteries) |
Type | For Canon/ Nikon and Sony Digital SLR cameras |
Wireless system | Radio category |
Radio specifications | 2.4GHz ISM band (Obtaining technical standards conformity certification) |
Channel | 8 channels (channel setting in Air 1) |
Flash | A, B, C (3 Groups) (Group control and a specific group can stop transmitting) |
Power source | Two size-AAA batteries |
Function mode | TTL, Manual and Manual zoom |
Flash interval | Fastest 10 times/second |
Number of flashes (Approx.) | 3,000 flashes |
Transmission distant | Max. 30m (Depending on the enviroment) |
Mode | [TTL] i-TTL ( Nikon) / E-TTL II / E-TTL (Canon) [manual] |
Manual zoom | Manual adjustment (24/35/50/70/85/105/135/200mm) |
EV compensation on flash | [TTL] -2.0 ~ + 2.0 ,1/2EV step [manual] 1 ~ 1/128 (8 steps) Each group can be adjusted independently or synchronized |
Flash exposure control | 1st- Curtain synchronization, 2nd- Curtain synchronization, High- speed synchronization, Red-eye reduction, Slow synchronization (only available on Nikon Model), FE / FV Lock (set on camera) |
AF-assist beam effective range | 0.7 ~ 5m |
Operation panel | LED color panel and select dial |
High-speed synchronization | 1/8,000 sec |
Dimensions | 65(L) x 60 (W) x 55 (H)mm/ 2.6(L) x 2.4(W) x 2.2 (H)inch |
Weight | 55g / 1.9oz (without batteries) |
