Netbúnaður aðgangspunktur Edimax EW-7478APC AC1200

Edimax

Fjölnota tæki með mjög góða þráðlausa drægni. Styður nýjasta WiFi 802.11ac staðalinn. Öll nettengin styðja 1000Mbps gagnahraða. Hægt að nota á fimm mismunandi vegu: ...

Fjölnota tæki með mjög góða þráðlausa drægni. Styður nýjasta WiFi 802.11ac staðalinn. Öll nettengin styðja 1000Mbps gagnahraða. Hægt að nota á fimm mismunandi vegu: router, aðgangspunktur, range extender, þráðlaus brú og WISP. Styður Dual Band, þ.e. virkar á bæði 2,4GHz og 5GHz þráðlausu neti.

  • Upplýsingar

Edimax EW-7478APC AC1200 Gigabit Dual-Band Access Point with USB

  • AC1200 High-Speed Concurrent Dual-Band: Max speed up to 300Mbps (2.4GHz) and 867Mbps (5GHz) with 802.11ac Wi-Fi standard and backward compatible with 802.11a/b/g/n standards.
  • Multi-Function USB Port: Storage & FTP file or printer sharing as your own private, secure cloud.
  • Multiple SSIDs with VLAN: Supports up to 8 SSIDs (2.4GHz x 4 & 5GHz x 4) and provides security to protect confidential or critical network resources (Access point mode only).
  • Plug and Play: Zero configuration setup with no CD required. Just connect the EW-7478APC to your router with an Ethernet cable.
  • Easy 11ac Upgrade: Upgrade your single-band 2.4GHz Wi-Fi to 11ac dual-band Wi-Fi for better coverage and faster Wi-Fi speed with zero configuration.
  • 5 Modes in 1: Access point, range extender, Wi-Fi router, Wi-Fi bridge and WISP.
  • Guest Network: Provides secure, private connectivity while isolating guests from your primary network (Wi-Fi router/range extender/WISP mode only).
  • iQoS Bandwidth Management: Efficient Internet bandwidth management
  • VPN (Virtual Private Network): Access secure remote networks from anywhere, protect privacy on public Wi-Fi and bypass Internet censorship (Wi-Fi router mode only).


Product description
AC1200 Gigabit Dual-Band Access Point with USB Port

Almennar upplýsingar

AC1200 High-Speed Concurrent Dual-Band: Max. speed up to 300Mbps (2.4GHz) and 867Mbps (5GHz) with 802.11ac Wi-Fi standard and backward compatible with 802.11a/b/g/n standards. Multi-Function USB Port: Storage, FTP file or printer sharing as your own private, secure cloud. Multiple SSIDs with VLAN: Supports up to 8 SSIDs (2.4GHz x 4 & 5GHz x 4) and provides security to protect confidential or critical network resources (Access point mode only). Plug and Play: Zero configuration setup with no CD required. Just connect the EW-7478APC to your router with an Ethernet cable. Easy 11ac Upgrade: Upgrade your single-band 2.4GHz Wi-Fi to 11ac dual-band Wi-Fi for better coverage and faster Wi-Fi speed with zero configuration. 5 Modes in 1: Access point, range extender, Wi-Fi router, Wi-Fi bridge and WISP. Guest Network: Provides secure, private connectivity while isolating guests from your primary network (Wi-Fi router/range extender/WISP mode only). iQoS Bandwidth Management: Efficient Internet bandwidth management VPN (Virtual Private Network): Access secure remote networks from anywhere, protect privacy on public Wi-Fi and bypass Internet censorship (Wi-Fi router mode only).   Official Product Link Open Link Port 1 x RJ-45 10/100/1000Mbps WAN port 4 x RJ-45 10/100/1000Mbps LAN port 2 x USB 2.0 port Button WPS/Reset buttons LED Indicator Power, Internet, WLAN, USB Antenna 2 x Dual-band antennas Memory 8MB NOR Flash 64MB RAM Power Adapter 12V DC, 1.5A Dimensions (W x D x H) 190.2mm x 172mm x 42mm Weight 322 grams Standards 802.11 a/b/g/n/ac Frequency 5GHz and 2.4GHz concurrent dual-band Maximum Data Speed 5GHz: 867Mbps 2.4GHz: 300Mbps Receive Sensitivity 5GHz: 11a(6Mbps): 90°±2dBm 11a(54Mbps): 71°±2dBm 11n(20MHz, MCS7): 69°±2dBm 11n(40MHz, MCS7): 65°±2dBm 11ac(80MHz, MCS9): -55°±2dBm 2.4GHz: 11b(1Mbps): 91°±2dBm 11b(11Mbps): 87°±2dBm 11g (54Mbps): 71°±2dBm 11n(20MHz, MCS7): 68°±2dBm 11n(40MHz, MCS7): 65°±2dBm Output Power 5GHz: 11a(6Mbps): 18°±1.5dBm 11a(54Mbps): 14°±1.5dBm 11n(20MHz, MCS7): 13°±1.5dBm 11n(40MHz, MCS7): 13°±1.5dBm 11ac(80MHz, MCS9): 13°±1.5dBm 2.4GHz: 11b (1Mbps): 18°±1.5dBm 11b (11Mbps): 16°±1.5dBm 11g (54Mbps): 14°±1.5dBm 11n (20MHz, MCS7): 13°±1.5dBm 11n (40MHz, MCS7): 13°±1.5dBm Guest Network 5GHz guest network 2.4GHz guest network Security 64/128-bit WEP, WPA and WPA2 security Hardware & software WPS configuration QoS for critical operations, SPI anti-DoS firewall Certification CE, FCC, RoHS Environmental Condition Operating humidity: 10-90% (non-condensing) Operating temperature: 32 - 104°F (0 - 40°C) System Requirement Cable or xDSL Internet connection (RJ-45 cable modem or RJ-45 ADSL modem) Computer (with Fast Ethernet adapter or wireless adapter) running Windows, Mac OS or Linux Smartphone, tablet or laptop running iOS 4 or Android 4 and above Web browser (Internet Explorer, Google Chrome, Firefox, Opera or Safari) Package Content EW-7478APC Access point Quick installation guide CD-ROM (including setup wizard, multi-language quick installation guide and user manual) Power adapter Ethernet cable Official Product Link Open Link Port 1 x RJ-45 10/100/1000Mbps WAN port 4 x RJ-45 10/100/1000Mbps LAN port 2 x USB 2.0 port Button WPS/Reset buttons LED Indicator Power, Internet, WLAN, USB Antenna 2 x Dual-band antennas Memory 8MB NOR Flash 64MB RAM Power Adapter 12V DC, 1.5A Dimensions (W x D x H) 190.2mm x 172mm x 42mm Weight 322 grams Standards 802.11 a/b/g/n/ac Frequency 5GHz and 2.4GHz concurrent dual-band Maximum Data Speed 5GHz: 867Mbps 2.4GHz: 300Mbps Receive Sensitivity 5GHz: 11a(6Mbps): 90°±2dBm 11a(54Mbps): 71°±2dBm 11n(20MHz, MCS7): 69°±2dBm 11n(40MHz, MCS7): 65°±2dBm 11ac(80MHz, MCS9): -55°±2dBm 2.4GHz: 11b(1Mbps): 91°±2dBm 11b(11Mbps): 87°±2dBm 11g (54Mbps): 71°±2dBm 11n(20MHz, MCS7): 68°±2dBm 11n(40MHz, MCS7): 65°±2dBm Output Power 5GHz: 11a(6Mbps): 18°±1.5dBm 11a(54Mbps): 14°±1.5dBm 11n(20MHz, MCS7): 13°±1.5dBm 11n(40MHz, MCS7): 13°±1.5dBm 11ac(80MHz, MCS9): 13°±1.5dBm 2.4GHz: 11b (1Mbps): 18°±1.5dBm 11b (11Mbps): 16°±1.5dBm 11g (54Mbps): 14°±1.5dBm 11n (20MHz, MCS7): 13°±1.5dBm 11n (40MHz, MCS7): 13°±1.5dBm Guest Network 5GHz guest network 2.4GHz guest network Security 64/128-bit WEP, WPA and WPA2 security Hardware & software WPS configuration QoS for critical operations, SPI anti-DoS firewall Certification CE, FCC, RoHS Environmental Condition Operating humidity: 10-90% (non-condensing) Operating temperature: 32 - 104°F (0 - 40°C) System Requirement Cable or xDSL Internet connection (RJ-45 cable modem or RJ-45 ADSL modem) Computer (with Fast Ethernet adapter or wireless adapter) running Windows, Mac OS or Linux Smartphone, tablet or laptop running iOS 4 or Android 4 and above Web browser (Internet Explorer, Google Chrome, Firefox, Opera or Safari) Package Content EW-7478APC Access point Quick installation guide CD-ROM (including setup wizard, multi-language quick installation guide and user manual) Power adapter Ethernet cable
Official Product Link Open Link
Port 1 x RJ-45 10/100/1000Mbps WAN port 4 x RJ-45 10/100/1000Mbps LAN port 2 x USB 2.0 port
Button WPS/Reset buttons
LED Indicator Power, Internet, WLAN, USB
Antenna 2 x Dual-band antennas
Memory 8MB NOR Flash 64MB RAM
Power Adapter 12V DC, 1.5A
Dimensions (W x D x H) 190.2mm x 172mm x 42mm
Weight 322 grams
Standards 802.11 a/b/g/n/ac
Frequency 5GHz and 2.4GHz concurrent dual-band
Maximum Data Speed 5GHz: 867Mbps 2.4GHz: 300Mbps
Receive Sensitivity 5GHz: 11a(6Mbps): 90°±2dBm 11a(54Mbps): 71°±2dBm 11n(20MHz, MCS7): 69°±2dBm 11n(40MHz, MCS7): 65°±2dBm 11ac(80MHz, MCS9): -55°±2dBm 2.4GHz: 11b(1Mbps): 91°±2dBm 11b(11Mbps): 87°±2dBm 11g (54Mbps): 71°±2dBm 11n(20MHz, MCS7): 68°±2dBm 11n(40MHz, MCS7): 65°±2dBm
Output Power 5GHz: 11a(6Mbps): 18°±1.5dBm 11a(54Mbps): 14°±1.5dBm 11n(20MHz, MCS7): 13°±1.5dBm 11n(40MHz, MCS7): 13°±1.5dBm 11ac(80MHz, MCS9): 13°±1.5dBm 2.4GHz: 11b (1Mbps): 18°±1.5dBm 11b (11Mbps): 16°±1.5dBm 11g (54Mbps): 14°±1.5dBm 11n (20MHz, MCS7): 13°±1.5dBm 11n (40MHz, MCS7): 13°±1.5dBm
Guest Network 5GHz guest network 2.4GHz guest network
Security 64/128-bit WEP, WPA and WPA2 security Hardware & software WPS configuration QoS for critical operations, SPI anti-DoS firewall
Certification CE, FCC, RoHS
Environmental Condition Operating humidity: 10-90% (non-condensing) Operating temperature: 32 - 104°F (0 - 40°C)
System Requirement Cable or xDSL Internet connection (RJ-45 cable modem or RJ-45 ADSL modem) Computer (with Fast Ethernet adapter or wireless adapter) running Windows, Mac OS or Linux Smartphone, tablet or laptop running iOS 4 or Android 4 and above Web browser (Internet Explorer, Google Chrome, Firefox, Opera or Safari)
Package Content EW-7478APC Access point Quick installation guide CD-ROM (including setup wizard, multi-language quick installation guide and user manual) Power adapter Ethernet cable
