Vörumynd

Aflgjafi Corsair TX750M 750W 80+Gold Modular

Corsair

Vandaður 80+ Gold Modular vottaður 750W spennugjafi. 80+ Gold vottun eykur nýtni aflgjafans og tryggir gæðin. Hljóðlátur og mjög áreiðanlegur aflgjafi með öllum helstu tengimöguleikum. Hen...

Vandaður 80+ Gold Modular vottaður 750W spennugjafi. 80+ Gold vottun eykur nýtni aflgjafans og tryggir gæðin. Hljóðlátur og mjög áreiðanlegur aflgjafi með öllum helstu tengimöguleikum. Hentar sérstaklega vel fyrir þá sem ætla að hafa eitt eða jafnvel tvö öflug skjákort í tölvunni. Ræður við allt að 62,5 A straum á 12V.

  • Upplýsingar

Corsair TX M Series TX750M 750W ATX Semi-Modular (80+Gold) Power supply (internal)

TX Series semi-modular power supplies are ideal for basic desktop systems where low energy use, low noise, and simple installation are essential. All of the capacitors are 105°C rated, Japanese brand, to ensure solid power delivery and long term reliability. 80 PLUS Gold efficiency reduces operating cost and excess heat. Flat, sleeved black modular cables with clearly-marked connectors make installation fast and straightforward, with good-looking results.

Features

  • 80 PLUS® Gold efficiency, delivering 90% energy efficiency at real world load conditions
  • Active PFC with full range AC input (100-240 VAC)
  • 120mm rifle bearing fan
  • Dimensions: 150mm x 86mm x 140mm
  • Engineered to meet maximum power output at a server-grade 50°C temperature rating
  • Over-voltage protection, under-voltage protection, short circuit protection, over power protection, and over temperature protection provide maximum safety to your critical system components
  • Safety and Agency Approvals: FCC, ICES, CE, UL, cUL, RCM, TÜV, CB, CCC, BSMI, EAC, RoHS, WEEE, KC

Compatibility

  • 6th generation Intel® Core™ processor Ready (Intel Skylake and Z170 motherboards)
  • ATX12V v2.4 and EPS 2.92 standards and is backward compatible with ATX12V 2.2, 2.31 and ATX12V 2.01 systems
    Tech Specs

Warranty

Seven years

Weight

1.7kg

MTBF

100,000 hours

80 Plus

Gold

Power

750 Watts

Fanless mode

No

Fan bearing technology

Rifle Bearing

Fan size (mm)

120mm

C-Link Digital

No

Continuous output rated temperature (°C)

50°C

Modular

Semi-Modular

Sleeved cables

Low-Profile, All Black

ATX Connector

1

EPS Connector

1

Floppy Connector

2

Four Pin Peripheral Connector

7

PCIe Connector

4

SATA Connector

8

Plug Type

EU

Package contents

  • TXM Series ATX Power Supply
  • Power cord
  • Modular cables
  • 100mm floppy adapter
  • Mounting screws
  • Cable ties
  • Corsair case badge
  • User manual
