Aflgjafi Inter Tech 650W 12CM Energon EPS650W

Inter-tech

Aflgjafiinn er 650 W og með hljóðláta 12 cm viftu.  Hann er fyrir PC tölvur og má nota í alla ATX og microATX tölvukassa.
Suðstyrkur: Minni en 21 d...

Aflgjafiinn er 650 W og með hljóðláta 12 cm viftu.  Hann er fyrir PC tölvur og má nota í alla ATX og microATX tölvukassa.
Suðstyrkur: Minni en 21 dB
Vottanir: CE/TUV/CB/UL/CUL/N/FCC
Tengi: 24/20 pinna ATX móðurborðstengi, 2 x Molex og 4 x SATA rafmagnstengi, 1x P4 4ra pinna örgjörvatengi og 6+2 pinna PCI-Express tengi
Hámarksálag við tiltekna rafspennu: +3.3V 28A, +5V 28A, +12V 18A, -12V 0,8A, +5Vsb 2,5A

  • Upplýsingar

Power Supply 650W Combat Power Plus 120mm Fan

Almennar upplýsingar

Power
Nominal power: 650W
AC input voltage: 115 - 230V
AC input frequency: 50 - 60 Hz
Input current: 3A
Power Factor Correction (PFC) type: Active
DC output voltage: +12V1, +12V2, +12V3, +12V4, +3.3V, +5V, +5Vsb, -12V
Combined power (+3.3V): 150W
Combined power (+12V): 550W
Combined power (+5V): 150W
Max output current (+3.3V): 28A
Max output current (+12V): 18A
Max output current (+12V1): 18A
Max output current (+12V2): 18A
Max output current (+12V3): 18A
Max output current (+12V4): 18A
Max output current (+5V): 28A
Max output current (-12V): 0.8A
Max output current (+5Vsb): 2.5A
Power protection features: Over current, Over voltage, Short circuit
Cooling
Fan diameter: 12 cm
Fan location: Top
Cooling type: Active
Number of fans: 1
Ports & interfaces
Motherboard power connector: 20+4 pin ATX
Number of SATA power connectors: 4
Peripheral (Molex) power connectors (4-pin): 2
EPS power connector (8-pin): Y
PCI Express power connectors (6+2 pin): 1
CPU power connector (4+4 pin): Y
Floppy drive power connector: 1
Performance
Form factor: ATX
Purpose: PC
ATX version: 2.2
Noise level: 21 dB
On/off switch: Y
Design
Colour of product: Black
Packaging data
Package dimensions (WxDxH): 200 x 200 x 95 mm
Package weight: 1.62 kg
Certificates
RoHS compliance: Y
Certification: CE, TUV, FCC
Weight & dimensions
Width: 15 cm
Depth: 14 cm
Height: 8.6 cm
Weight: 1.28 kg
