Vörumynd

Aflgjafi MicroATX FSP 270W LC-200SFX

Sparkle

Aflgjafiinn er 270 W og hentar fyrir litlar MicroATX borð og turntölvur.
Vottanir: CE/TUV/CB/UL/CUL/N/FCC
Tengi: 1x 20 pinna m...

Aflgjafiinn er 270 W og hentar fyrir litlar MicroATX borð og turntölvur.
Vottanir: CE/TUV/CB/UL/CUL/N/FCC
Tengi: 1x 20 pinna móðurborðstengi, 3 x Molex og 1 x floppy rafmagnstengi, 1x P4 4ra pinna örgjörvatengi
Yfirálagsvörn: Fyrir +5V, +3,3V og +12V
Mál: (breidd x lengd x hæð) 125 x 130,3 x 63,5 mm

  • Upplýsingar

Almennar upplýsingar

Sparkle FSP270-SNV 270W M-ATX Power Supply Specifications Mfr..Part Number: FSP270-50SNV Features: Passive PFC(Power Factor Correction) circuit at 230 V AC High efficiency Low ripple & Noise Output over voltage protection Short circuit protection on all output Safety approved: CSA, UL, IEC, TUV, NEMKO, CE 100% burn-in under high ambient temperature (50XC) Vacuum-impregnated transformer MTBF: 100K hours at 25°C 100% Hi-pot tested Line input fuse protection With 8cm fan Input: Voltage: 230 VAC Frequency: 47 ~ 63Hz Input current: 3 amps maximum / 230 Vrms, 50 Hz Inrush current: 80 amps cold, 90 amps warm measured at 264 Vrms Total Watts: 270 W Connectors: 1x 20pin main power; 1x 4pin P4; 3x peripheral; 1x floppy Remote ON/OFF Control: The Power supply shall accept a logic open collector level which will disable /enable all out put voltage (excluding +5V standby) Transient response: output voltage recovers in less than 1 ms max. following a 25%load change Hold-up time: 10.0ms minimum (at 230V / 50 Hz) Dielectric withstand: input / output 1800VAC for1 second, input to frame ground 1800VAC for 1 second Efficiency: 65% min. at full load Power good signal: turn-on delay 100~500 ms Over voltage protection: +5V, +3.3V, +12V Dimension (WxLxH): 125 x 130.3 x 63.5 mm
